基于SPR增强的开放式悬挂芯光纤集成芯片

谭绪祥; 王冠军; 王志斌

doi:10.7510/jgjs.issn.1001-3806.2016.02.012

基于SPR增强的开放式悬挂芯光纤集成芯片

1.
中北大学仪器科学与动态测试教育部重点实验室, 太原 030051;
2.
中北大学电子测试技术重点实验室, 太原 030051

作者简介: 谭绪祥(1987-),男,硕士研究生,现主要从事光传感与光电探测方面的研究。.

通讯作者: 王冠军, wangguanjun@163.com ;

基金项目:
国家自然科学基金资助项目(61405127);山西省青年基金资助项目(2014021023-1);中国博士后科学基金资助项目(2014M562202)
中图分类号: TN253

Opened suspended core fiber chip based on surface plasma resonance enhancement mechanism

1.
Key Laboratory of Instrumental Science & Dynamic Measurement of Ministry of Education, North University of China, Taiyuan 030051, China;
2.
Science and Technology on Electronic Test & Measurement Laboratory, North University of China, Taiyuan 030051, China

Corresponding author: WANG Guanjun, wangguanjun@163.com ;

CLC number: TN253

摘要: 为了有效提升光纤表面等离子体共振(SPR)传感器场增强效果的响应速度和场增强特性,采用悬挂芯光纤结合表面等离子体共振增强检测机理来提高表面场增强程度,提出了一种新型的光纤SPR-表面场增强芯片结构。采用有限元理论分析了上述结构的光场特性,由分析可知,当薄膜层在40nm~50nm附近时存在比较强的场增强;场增强程度与激发SPR共振波长密切相关;而缩小包层厚度、降低纤芯折射率对比度也有利于大幅度增加场增强强度,但半径和包层厚度变化对穿透深度几乎没有影响。结果表明,优化后的光纤芯片具有较高的场增强效果。该研究为高灵敏、快速流体检测应用提供了一种解决思路。
- 光纤光学 /
- 表面等离子体共振 /
- 开放式悬挂芯光纤 /
- 光纤芯片
Abstract: For solving the problems of low surface intensity enhancement and slow response speed of fiber surface plasma resonance (SPR) sensors, a new type of optical fiber SPR-induced surface enhancement chip structure was proposed by using the mechanism of surface plasma resonance to improve the surface field enhancement degree. The characteristics of the proposed chip structure were analyzed based on the finite element method. When Au film layer thickness was near 40nm~50nm, a stronger field enhancement appeared. The degree of field enhancement was closely related with the transmitting wavelength. Reduction of cladding thickness, core diameter and refractive index contrast could increase the degree of field intensity enhancement, but radius and thickness of cladding had almost no effect on penetration depth. The results show that a good surface enhancement effort is feasible after optimization. The study could be beneficial for the application of fluid testing with high sensitivity and rapidity.
- fiber optics /
- surface plasma resonance /
- opened suspended core fiber /
- fiber chip
